not really no. If it doesn’t come with a 6-pin, it can’t properly provide the power a 6-pin needs.
Can a 4-pin power a 6-pin?
It will be fine. It’ll be notched in a way that you can only plug it in the proper way.
What are Molex 4-pin connectors for?
The Molex 4-pin power supply connector is one of the standard peripheral power connectors in computers today. This power connector is the standard connector for all PATA based hard drives, many high-end video cards, and some older optical drives and other internal devices.
Is Molex to SATA safe?
Molex to SATA adapter cables are a very simple and cost-effective alternative to buying a new power supply. However, they can be a dangerous alternative to getting a quality power supply, potentially damaging your SSD, internal components, and may also pose a fire risk in your home.
How much power can a Molex supply?
54 watts
The ATX standard for SATA or Molex connections is rated for 54 watts. Each SATA/Molex connector provides three 12v pins at 1.5 amps each, for a total of 4.5 amps. 12 volts, times 4.5 amps, equals 54 watts able to be provided by a SATA/Molex connector. Some PCIe risers do not conform to ATX specifications.
Do you need 4 pin CPU power connector?
4 pin is for extra stability when overclocking etc. It is not necessary to use the additional 4 pin connector if you’re not pushing the board or CPU too hard. Basic everyday computing and gaming won’t require it. It’s definitely not needed for normal operation or even a slight overclock.
Can CPU use 6 pin?
the 4 + 2 (6 pin) is probably for your video cards and probably will not work plugging into the CPU power.
Is Molex still used?
Basically since around 2006 IDE and their molex powered devices are zero. And everything now is now SATA power. Motherboards have no IDE connectors on them no more, and any DVD drives and hard drives you buy all come with SATA power connectors and no more Molex support.
Which is better Molex or SATA?
Technically Molex can carry much more power than the SATA power connector. Molex has 2 power pins (one 5V and on 12V pin), each can deliver 11Amps for a total of 22Amps. The other 2 pins are ground wires… SATA power connectors has a total of 15 pins of which 9 are power pins (3 x 3.3V, 3 x 5V, 3 x 12V).
Can Molex power a hard drive?
Regarding your original question though, if the psu has 4pin molex plugs it’s fine to use. The hdd can use either.
How much power does 6 pin connector provide?
A 6-pin power connector can supply 75 Watt to the graphics card. So if your graphics card power consumption is more than 75W then it will have one 6-pin PCI-E power connector for its working.
What are Molex pins?
Molex Incorporated is a manufacturer of electronic, electrical and fiber optic interconnection systems. They manufacture all kinds of connectors (read : pins). Hence Molex Pins in general could mean any of the connectors manufactured by molex.
What is a 6 pin PCIe power connector?
PCI Express (PCIe) 6pin power 01 Mar 1998 This connector is used to provide extra 12 volt power to PCI Express expansion cards . Many video cards draw significantly more than 75 watts provided by the motherboard slot, so the 6 pin PCI Express power cable was created.
What is a 6 pin connector?
The ATX 6 pin power supply connector is a motherboard power connector used to provide +12 VDC to the processor voltage regulator. This 6-pin connector is also sometimes used to provide extra power to high-end video cards.
