To find out the size of bottom bracket needed, measure the inside of the bottom bracket shell in your frame, it will be 73mm, 70mm or 68mm. Some older frames may have Italian threaded bottom brackets, instead of the more modern English.

How do I determine bottom bracket spindle length?

Pull off both crank arms, then measure the spindle of the BB, that’s what the Shimano Crank is saying it needs. When you measure spindle length, you need to only measure to the ends of the square taper. Some spindles have threaded bits that extend beyond the square taper. Don’t include those in that measurement.

Does spindle length matter on bottom bracket?

The critical thing is your spindle length: as long as you can set up the correct chainline you will be good to go. But, again, best never to mix standards if you can at all avoid it. If you are looking to replace a cottered crank setup with a square taper setup, then look no further than a cartridge bottom bracket.

What is 68mm bottom bracket?

The 68mm and 73mm dimension measure the width of the bottom bracket on the frame of the bike with no BB installed, simply the width of the shell. Most road bikes that use a threaded bottom bracket measure 68mm wide and most cross country/trail mountain bikes measure 73mm.

What length spindle do I need?

If you have a Mid or a Spanish BB on your BMX Freestyle bike, you need the 5 5/8″ spindle. If you have an American BB on almost any style of frame, you need the 5 5/8″ spindle. If you are using the Outboard BB and the Spline Drive Sprocket, and you BB shell measures 68mm wide, you need the 5 5/8″ Spindle.

What is bottom bracket spindle length?

Some downhill bikes even use an 83 mm (3.3 in) bottom bracket shell. Snow bikes use a 100 mm (3.9 in) shell. Spindles come in a wider range of lengths (102–140 mm [4.0–5.5 in]), and are sized to match not only the shell width but also the type of crankset it will support (longer for triple, shorter for single, etc.).

Will a 68mm bottom bracket fit a 73mm shell?

You could install it, but it will shift your chainline, shift the centerline of your feet, clearance issues might arise on the non-drive side, and you might be leaving some BB shell threads exposed on the non-drive side as well.

What’s the difference between 170mm and 175mm cranks?

Whereas now 170 is ‘short’ 172.5mm is ‘normal’ and 175 mm cranks are very common. Still though, the difference between 170 mm and 175mm is less than 3% and leg lengths of bike riders vary by far more than that.

What is the standard size of a bottom bracket?

This is the overall length of your bottom bracket. The length typically ranges from 113-122 mm. If you’re replacing a bottom bracket, the length of your new bracket must match the length of your old bracket.

Are all Shimano cartridge bottom brackets interchangeable?

Shimano Cartridge Bottom Brackets 1 Model designations include: Square Taper: CT21, LP27, UN40, UN51, UN52, UN71, UN72, UN91. These are all interchangeable if the other numbers match. 2 Shell width in millimeters: 68 for standard ISO/British 70 for Italian 73 for oversized ISO/British. 3 Length: overall spindle length in millimeters.

What thread size is frameframe bottom bracket shell?

Frame’s bottom bracket shell is threaded with M47 x 1 threads. Right hand threads on the non-drive. * Essentially a PF30 with 86.5mm wide shell. * Essentially a PF30 with 92mm wide shell.
