Reset to factory default Switch the thermostat to Off Mode. Press and hold the lower left corner of touch screen for five (5) seconds. The thermostat then resets itself, displays its current firmware version, and restarts in Off Mode.
How do I unlock my radio thermostat?
To UNLOCK , Press MENU. Touch and hold icon for 5 seconds for 2 bars (if not there already). Then touch and hold the icon for another 5 seconds. Each 5 second touch and hold must be separate.
How do I adjust the temperature on my CT100 thermostat?
85ºF 78ºF 82ºF The CT100 thermostat automatically includes EPA recommended heating and cooling programs. If it does not fi t your needs, you can adjust the programs instead. To run one of these preset programs, simply set the thermostat mode to Heat or Cool.
What is the manual screen on a CT100?
CT100 Operation Guide Customization Manual Screen The Manual screen enables you to make temporary changes to how your CT100 operates. Features you can control on the Manual screen: Thermostat Mode, Fan Mode, Target Temperature Override, and more. The following pages provide detailed function settings. Page 36 Manual screen.
How do you wire a CT100 aux heat pump?
1. Connect the W and W2 wires to the W and W2 terminals. Page 21 HVAC SYSTEM Stage Aux Heat AUX1 AUX2 POWER The CT100 can handle up to 2 stages of Pump compression and 2 stages of AUX heat. 1. Connect O wire to the O terminal C B O W RC G A or the B wire to the B terminal.
How do I connect my thermostat to my Network?
Set your primary controller to INCLUDE mode to add the thermostat as a node on your network (see your specifi c controller’s User Manual for detailed instructions). 2. From the CT100’s Menu screen, touch MATE under the radio icon. The Network Include screen displays a large r1.
