A thermostatic bin control sensor uses a thermostatic bulb hanging from the ice maker to determine the ice level in the bin. The bulb contains temperature-sensitive fluid that expands when the temperature drops.
How do you test a Hoshizaki bin switch?
To test the control, allow the unit to cycle into freeze for approximately 1 minute. Push the actuator to the right and the unit should shut down within 3 ~ 5 seconds. When you remove your hand, the unit should restart in the 1 minute fill cycle within 3 ~ 5 seconds.
Where is the bin switch on an ice machine?
Manitowoc bin switches are the part of the ice machine that tell the control board when a batch of ice has dropped or when the ice bin is full. They are mounted to the underside of the evaporator, where the magnet of the water curtain or damper door make contact.
What does a bin thermistor do?
Consisting of a thermistor inside a small case, is used to sense air temperature. This part monitors the temperature and sends the readings to the electronic control board.
What is a bin switch?
The bin switch is a magnetically operated reed switch. The magnet is attached to the lower right corner of the water curtain/ice dampers. The switch is attached to the right bulkhead wall.
How do I turn off my Hoshizaki Ice Maker?
How Do I Turn Off a Hoshizaki Ice Maker?
- If you are able, simply unplugging the Hoshizaki ice machine is the best way to turn it off.
- If you cannot unplug the ice machine, the next best course of action is to locate the breaker that your ice machine is on and turn it to “off”
How do you adjust the thickness of ice?
1. Turn adjustment screw (Figure 4) on ice thickness probe clockwise to increase ice thickness, counterclockwise to decrease ice thickness.
How long does it take for a Hoshizaki ice machine to make ice?
We show two production capacities for each machine: Max and AHRI. Max production in 24 hours is based water that is 50 degrees and surrounding air at 70 degrees.
What does a curtain switch do?
A water curtain will have either enclosed or mounted to the outside a small magnet. This magnet is what makes a proximity switch known as a magnetic bin switch. When the water curtain swings closed and remains closed it tells the ice maker that the bin is still empty and to continue making ice.
Where is the thermistor on a Hoshizaki ice machine?
evaporator outlet
The thermistor is mounted to the evaporator outlet or suction line. It is sealed to the suction line using a high heat conductive sealant (Hoshizaki part number 60Y000-D1 or Radio Shack item number 276-1372).
How do you test a thermistor on an ice maker?
Testing the operation of these sensors is quite simple: Remove the sensor from the controller and allow the thermistor to approach room temperature. Place an ohmmeter across the leads of the thermistor and record its resistance value. Then place the thermistor in an ice bath.
