The software is available free of charge, and can be installed on as many machines as you like.
How do you use Saleae?
To power on your Saleae, simply connect it to your computer via the included USB cable, to get started with it, you’ll need to download the Logic software which is available on the Saleae website. Once installed, the software will automatically recognise your Saleae model and open into the capture screen.
How do you say Saleae?
Saleae is pronounced say-lee-a, with the emphasis (stress) on the first syllable, as in SAY-lee-a.
What is a logic analyzer used for?
A logic analyzer is an excellent tool for verifying and debugging digital designs. A logic analyzer verifies that the digital circuit is working and helps you troubleshoot problems that arise. The logic analyzer captures and displays many signals at once, and analyzes their timing relationships.
How do I connect Saleae?
- Open the Logic software.
- Connect one end of the included USB cable to the Logic analyzer.
- Connect the other end of the USB cable to the PC’s USB port.
- Once connected to the PC, the software will begin configuring the device and the LED on Logic should turn on.
Which protocols are understood by the Saleae logic Analyser?
The Saleae Logic software includes the following protocol analyzers:
- Asynchronous Serial.
- I2C.
- SPI (Serial Peripheral Interface)
- CAN (Controller Area Network)
- DMX512.
- I2S Audio / PCM.
- Manchester, Differential Manchester, Bi-Phase Space, and Bi-Phase Mark.
- 1-Wire.
How do I use Saleae logic Analyser?
How to Use a Logic Analyzer
- Connect probes to the system under test.
- Set your sampling mode.
- Configure the trigger conditions.
- Acquire signal data.
- Display and analyze waveforms.
How does a logic Analyser work?
A logic analyzer reacts the same way as a logic circuit does when a single threshold is crossed by a signal in the system. It recognizes the signal to be either low or high. It can also trigger on patterns of highs and lows presented on these signals.
Should I buy an oscilloscope or a logic analyzer?
Oscilloscopes are the best tools for measuring and viewing analog electronic signals, and for evaluating signal integrity and analog circuit performance. Logic analyzers are the best tools for measuring and viewing digital electronic signals, and digital protocols like I2C, SPI, and Serial.
How do I set up a Saleae logic analyzer?
Connecting the Logic Analyzer
- Open the Logic software.
- Connect one end of the included USB cable to the Logic analyzer.
- Connect the other end of the USB cable to the PC’s USB port.
- Once connected to the PC, the software will begin configuring the device and the LED on Logic should turn on.
How do you use a logic analyzer for Saleae?
How do I connect Saleae logic analyzer?
