Orange
Resistor Band Colors
| Color | Value |
|---|---|
| Red | 2 |
| Orange | 3 |
| Yellow | 4 |
| Green | 5 |
How do you read a 3 band resistor?
For a 3-band resistor color codes, the first two bands always denote the first two digits of the resistance value while the third band represents the multiplier. In the example we have, the bands are brown, black and brown. The first band is the brown band closest to the edge.
How is a 2.6 K resistor color code?
Note: Color code: red blue red red. Package of 300. Resistor, carbon film. Resistance: 2.6K Ohm.
How do you calculate resistance color code?
Reading and Determining the Resistor Value Hold the resistor with the gold or silver band to the right and read the color codes from the left to the right. Select the color codes from the bands on the resistor. Read the colors from left to right. The resistance value based on the color code provided is now displayed.
How do you identify a resistors color?
Resistor Color Chart Hold the resistor with the closely grouped bands to your left and read the resistor from the left to the right. For 5% and 10% resistors hold the resistor with the silver or gold band to the right and read the resistor from the left to the right. The first band will never be silver or gold.
What is resistor color coding chart?
The four band color code is the most common variation. These resistors have two bands for the resistance value, one multiplier and one tolerance band. In the example shown here, the 4 bands are green, blue, red and gold. By using the color code chart, one finds that green stands for 5 and blue for 6.
How is a 3.9 K resistor color code?
3.9K Ohm Resistor Color Code: Orange, White, Red, Golden.
What color is a 470 ohm resistor?
470 Ohm Resistor Color Code: Yellow, Violet, Brown, Golden.
What is colour coding of resistor?
Resistor Color Coding uses colored bands to quickly identify a resistors resistive value and its percentage of tolerance with the physical size of the resistor indicating its wattage rating. The colors brown, red, green, blue, and violet are used as tolerance codes on 5-band resistors only.
What are the color codes of resistors?
Black
What are the colors of a resistor?
Resistor Color Code Chart and Resistance Calculator. Resistors have standard colors for identification of the resistance value. In order, the colors are: black, brown, red, orange, yellow, green, blue, violet, gray, and white. Reading resistors is a very simple procedure if you use the chart and formula below.
What is the color code for a resistor?
The standard color coding method for resistors uses a different color to represent each number 0 to 9: black, brown, red, orange, yellow, green, blue, purple, gray, white. On a 4 band resistor, the first two bands represent the significant digits. On a 5 and 6 band, the first three bands are the significant digits.
