What is a Torque-arm, anyway? It’s a long suspension arm that attaches between the rear axle housing and the chassis. Its primary job is to control axle housing rotation. It has to be used with a lateral location device such as a Panhard Bar.
Is torque arm suspension independent?
BMR’s torque arm suspension system isolates these two functions by using coilovers in addition to lower control arms. Having independent control of each function allows each component to do its job more effectively and without compromise.
What is a torque arm on a truck?
A radius rod (also called a radius arm, torque arm, torque spring, and torsion bar) is a suspension link intended to control wheel motion in the longitudinal (fore-aft) direction.
Are torque arms necessary?
500 watts is about the limit you’d want to put in rear aluminum dropouts without a torque arm. If you have a 500 watt motor in the front, especially if you have an aluminum fork, you’ll want to use a torque arm. 750 watts or above should almost always use a torque arm, even in the rear of the bike, even in steel.
How is torque arm measured?
A practical way to calculate the magnitude of the torque is to first determine the lever arm and then multiply it times the applied force. The lever arm is the perpendicular distance from the axis of rotation to the line of action of the force. and the magnitude of the torque is τ = N m.
How do torque Arms work?
A torque arm is an extra piece of support metal added to a bicycle frame to more securely hold the axle of a powerful hubmotor. Torque arms are there to help your bicycle’s dropouts (the part of the bike that holds onto the axles of the wheels) resist the torque of an electric hubmotor.
Which suspension is a trailing arm?
A trailing-arm suspension, sometimes referred as trailing-link is a vehicle suspension design in which one or more arms (or “links”) are connected between (and perpendicular to and forward of) the axle and a pivot point (located on the chassis of a motor vehicle).
Where is the torque arm?
The torque arm is a suspension component that mounts on a rear-wheel drive vehicle’s rear-drive axle. This arm allows the vehicle to accelerate in a straight line without rotating the rear axle. This arm also assists the vehicle in braking by applying force to the braking system.
Do you need two torque arms?
Hub motors put a lot of twisting torque on a bicycles drop outs, more than any bike was designed for. To be extra cautious, with aluminum forks and powerful motors, you should use two torque arms, one on each side of the fork. …
How do I adjust the torque arm on my skis?
Adjusting the length of the limiter strap will change the front torque arm angle. Shortening the strap limits the extension of the front of the suspension; reducing the angle of the torque arm and increasing ski pressure during acceleration.
What does the torque arm do on a Ford Mustang?
The Torque Arm controls axle housing rotation during acceleration and braking, and the Panhard Bar controls the side-to-side position of the axle housing. With each part dedicated to a specific job, each can perform its function without compromise, greatly improving the performance of your Mustang.
Does the mm torque-arm suspension system increase the rear spring rate?
Yes, but only the rear springs… To take full advantage of the improved rear grip provided by the MM Torque-arm Suspension System, the rear spring rate should be increased from what is typical with a 4-link suspension. This will help optimize the handling balance so your Mustang will have the best performance possible.
How do I find the torque rating for my torque-arm?
On the row with your rear gear ratio, look to the right. The next two columns have the rear wheel torque ratings for each Torque-arm. The first is the maximum rear wheel torque rating for the Standard-Duty Torque-arm. The second is the maximum rear wheel torque rating for the Heavy-Duty Torque-arm.
