Router(config)# router eigrp autonomous_system_# This command will enable EIGRP routing protocol in router. We can use any ASN (Autonomous System Number) from 1 to 65,535. In order to become EIGRP neighbors this number must be same on all participates.

What are the commands for RIPv2?

This is a good time to point out that you still specify classful networks with the network command. According to the classful, network specified, the subnets of that network are automatically identified and participate in the routing update. By default routing updates are summarized at network boundaries.

What are the steps to configure EIGRP?

EIGRP Configuration Step by Step: a cisco packet tracer lab

  1. Step1: Assign ip addresses on Router Interfaces as well as PC’s as mentioned in topology diagram.
  2. Step 2: EIGRP configuration on R1:
  3. Step 3: EIGRP Configuration on R2:
  4. Step 4: EIGRP Troubleshooting command.
  5. Check Routing Protocol on R1 Router for EIGRP:

How do I configure EIGRP and RIP on the same network?

  1. Enter configuration commands, one per line. End with CNTL/Z. Router(config)#hostname R2.
  2. R2(config)#router rip. R2(config-router)#version 2. R2(config-router)#network 20.0.0.0.
  3. R2(config)#router eigrp 1. R2(config-router)#network 20.0.0.0.
  4. R2(config)#interface se0/0/1. R2(config-if)#ip address 30.0.0.1 255.0.0.0.

How do I enable IPv6 on EIGRP?

Configure the EIGRP for the IPv6 routing:

  1. Enable the IPv6 routing on a router.
  2. Assign the router ID of the each router.
  3. Enable the EIGRP for IPv6 routing on every router.
  4. Configure the EIGRP for IPv6 by using the AS 1 on a gigabit Ethernet and serial interfaces on a router.
  5. Determine a neighbor adjacency.

What is EIGRP command?

Enhanced Interior Gateway Routing Protocol (EIGRP) is a dynamic routing network-layer Protocol which works on protocol number 88. EIGRP supports classless routing, VLSM, route summarization, load balancing, and many other useful features.

Which statement is correct in RIPv2?

Explanation : RIPv2 is pretty much just like RIPv1. It has the same administrative distance and timers and is configured just like RIPv1.

Which of the following commands will enable RIPv2 on a router?

On router R1, in the global configuration mode, enter the router rip command to enable RIP. In the RIP configuration mode, change the version of the protocol to 2 by using the version 2 command. Next, use the network 10.0. 0.0 command to include the Fa0/1 interface on the router R1 in the routing process.

What is EIGRP configuration?

EIGRP (Enhanced Interior Gateway Routing Protocol) is an enhanced distance vector protocol that uses Diffusing Update Algorithm (DUAL) for shortest path calculation. Basic configuration enables EIGRP routing process and tells EIGRP which interfaces to include in routing process locally.

What command starts the EIGRP routing process?

To start an EIGRP for IPv6 routing configuration process, provide command as ipv6 router eigrp 1, where AS number is denoted as 1. The EIGRP for the IPv6 needs the 32 bit address for a router ID. Then use the command router id to configure a router ID in a router configuration mode.

How do I configure the RIPv2 version 2?

Configuring RIPv2 is a pretty straightforward process. Only three steps are required: 1. enabling RIP by using the router rip global configuration command. 2. instructing the router to use RIPv2 by typing the version 2 command. 3. telling RIP which networks to advertise by using one or more network commands. The first two commands are easy

How to redistribute EIGRP to RIPv2?

Unlike earlier method of EIGRP configuration, the additional commands like “no auto-summary”, “redistribute” go under the “topology base” mode under the ipv4 address family, which allows us to configure topology specific components. When redistributing EIGRP into RIPv2, the seed metric is set as infinite by default.

What is the third command of the RIP protocol?

The third command defines the networks directly connected to this router that will be participating in the RIP process. Even though RIP version 2 is a classless protocol, its configuration follows a classful criteria and so the network you specify there is a major classful network number.

How do I change the version of Rip in Linux?

Configuring RIPv2. To do that, we first need to enable RIP on both routers and then advertise these subnets using the network command. On router R1, in the global configuration mode, enter the router rip command to enable RIP. In the RIP configuration mode, change the version of the protocol to 2 by using the version 2 command.
