ETAP Arc Flash Analysis provides multiple capabilities for faster and easier performance. ETAP Arc Flash Analysis allows you to identify and analyze high risk arc flash areas in your electrical system, and it also allows simulation of several different methods used by engineers to mitigate high incident energy.
What is arc flash analysis in power system?
An Arc Flash Assessment / Analysis is a study of the facility’s power system to determine the incident energy available at specific electrical devices that employees would be exposed to while “interacting with” the electrical equipment at the facility.
How much does arc flash software cost?
If you have a relatively small facility the costs will be significantly less than a large scale operation (most of the time)… think on the low low end $3000, small to medium $7500 to $15,000 and on the high end $75,000 to $100,000.
What are the three hazards of arc flash?
An arc flash can cause minor injuries, third degree burns and potential death as well as other injuries including blindness, hearing loss, nerve damage and cardiac arrest.
What is arc flash study in ETAP?
ETAP Arc Flash Analysis allows you to identify and analyze high risk arc flash areas in your electrical system, and it also allows simulation of several different methods used by engineers to mitigate high incident energy.
Why arc flash is required?
Arc-Flash Hazard Assessments are required by OSHA and NFPA 70E as a part of an Electrical Hazard Assessment. Arc-Flash Assessments are a serious life safety issue and essential part of a safe and comprehensive electrical safety program.
Why is arc flash so harmful?
According to the National Institute for Occupational Safety and Health (NIOSH), five to 10 arc flash incidents occur each day in the U.S. Arc flash is extremely dangerous because it can produce some of the highest temperatures known to occur on earth, up to 35,000 degrees Fahrenheit, which is four times the temperature …
Is an arc flash study required?
Arc-Flash Hazard Assessments are required by OSHA and NFPA 70E as a part of an Electrical Hazard Assessment. Knowing what OSHA requires and how NFPA 70E can help meet the requirements will not only keep workers safe, but will also increase productivity and profitability for employers.
What voltage is arc flash PPE?
Each piece of equipment operating at 50 volts or more and not put into a deenergized state must be evaluated for arc flash and shock protection.
What is ETAP arc flash analysis?
Arc Flash software identifies and analyzes high risk arc flash areas in AC systems. DC Arc Flash module calculates the incident energy for direct current networks. ETAP Arc Flash Analysis provides multiple capabilities for faster and easier performance.
What is included in the arc flash analysis module?
The Arc Flash Analysis module also includes comprehensive single phase and three phase arc flash calculations as well as an invaluable arc flash analyzer tool to summarize results from the arc flash study. DC Arc Flash and ArcFault are offered as a separate modules. NFPA 70E, CSA Z462, NESC C2,…
What is an arc flash calculator?
ETAP Arc Flash Calculators provide a powerful graphical tool for rapid assessment of multiples or batches of “what if” scenarios. Improve safety & minimize equipment damage by validating arc flash mitigation techniques. Learn more
How does the automated arc flash labeling software work?
The Automated Arc Flash Labeling Software generates arc flash labels for every incoming main circuit breaker cubicle, load circuit breaker, & motor starter bucket Generate arc flash labels for every load terminal point including induction motors, synchronous motors, capacitor banks, & static loads
